问基于迭代自适应阈值和形状分析的圆形目标聚类检测

EN

/*
 * cv::Mat dst[3] is the result of the absolute difference between original and convolved channel.
 * MCF(std::vector<cv::Point>, int, int) is a filter function that returns an positive int only if the input contour is valid.
 */

/* Allocate 3 matrices (1 per channel)*/
cv::Mat accu[3];

/* We define the maximal threshold to be tried as half of the absolute maximal value in each channel*/
int maxBGR[3];
for(unsigned int i=0; i<3;i++){
    double min, max;
    cv::minMaxLoc(dst[i],&min,&max);
    maxBGR[i] = max/2;
    /* In addition, we fill accumulators by zeros*/
    accu[i]=cv::Mat(compos[0].rows,compos[0].cols,CV_8U,cv::Scalar(0));
}
/* This loops are intended to be multithreaded using
#pragma omp parallel for collapse(2) schedule(dynamic)
For each channel */
for(unsigned int i=0; i<3;i++){
    /* For each value of threshold (m_step can be > 1 in order to save time)*/
    for(int j=0;j<maxBGR[i] ;j += m_step ){
            /* Temporary matrix*/
            cv::Mat tmp;
            std::vector<std::vector<cv::Point> > contours;
            /* Thresholds dst by j*/
            cv::threshold(dst[i],tmp, j, 255, cv::THRESH_BINARY);
            /* Finds continous regions*/
            cv::findContours(tmp, contours, CV_RETR_LIST, CV_CHAIN_APPROX_TC89_L1);
            if(contours.size() > 0){
                /* Tests each contours*/
                for(unsigned int k=0;k<contours.size();k++){
                    int valid = MCF(contours[k],m_minRad,m_maxRad);
                    if(valid>0){
                        /* I found that redrawing was very much faster if the given contour was copied in a smaller container.
                         * I do not really understand why though. For instance,
                         cv::drawContours(miniTmp,contours,k,cv::Scalar(1),-1,8,cv::noArray(), INT_MAX, cv::Point(-rect.x,-rect.y));
                         is slower especially if contours is very long.
                         */
                        std::vector<std::vector<cv::Point> > tpv(1);
                        std::copy(contours.begin()+k, contours.begin()+k+1, tpv.begin());
                        /* We make a Roi here*/
                        cv::Rect rect = cv::boundingRect(tpv[0]);
                        cv::Mat miniTmp(rect.height,rect.width,CV_8U,cv::Scalar(0));
                        cv::drawContours(miniTmp,tpv,0,cv::Scalar(1),-1,8,cv::noArray(), INT_MAX, cv::Point(-rect.x,-rect.y));
                        accu[i](rect)    = miniTmp + accu[i](rect);
                    }
                }
            }
        }
    }
/* Make the global scoreMap*/
cv::merge(accu,3,scoreMap);
/* Conditional noise removal*/
if(m_minRad>2)
    cv::medianBlur(scoreMap,scoreMap,3);
cvtColor(scoreMap,scoreMap,CV_BGR2GRAY);
