问Deneb & PowerBI:风险矩阵项目

EN

{
  "$schema": "https://vega.github.io/schema/vega-lite/v5.json",
  "data": {"name": "dataset"},
  "width": 500,
  "height": 500,
  "encoding": {
    "y": {
      "field": "Exposure",
      "type": "ordinal",
      "sort": ["high", "medium", "low"]
    },
    "x": {
      "field": "Damage",
      "type": "ordinal",
      "sort": ["low", "medium", "high"],
      "axis": {"labelAngle": 0}
    }
  },
  "layer": [
    {
      "encoding": {
        "opacity": {
          "condition": {
            "test": {"field": "__selected__", "equal": "off"},
            "value": 0.3
          }
        }
      },
      "mark": {
        "type": "rect",
        "color": {
          "expr": "(datum['Exposure'] == 'high' & datum['Damage'] == 'high') || (datum['Exposure'] == 'high' & datum['Damage'] == 'medium') || (datum['Exposure'] == 'medium' & datum['Damage'] == 'high') ? 'red' : (datum['Exposure'] == 'medium' & datum['Damage'] == 'medium') || (datum['Exposure'] == 'high' & datum['Damage'] == 'low') || (datum['Exposure'] == 'low' & datum['Damage'] == 'high') ? 'orange': 'green'"
        }
      }
    },
    {
      "mark": {
        "type": "text",
        "fontSize": 16,
        "fontWeight": "bold",
        "color": "white"
      },
      "encoding": {"text": {"field": "Risk Count", "type": "quantitative"}}
    }
  ],
  "config": {"axis": {"grid": true, "tickBand": "extent"}}
}
