k8s通过elk+kafka采集业务日志

本文介绍如何在k8s集群中通过filebeat采集日志，然后通过kafka将日志发给logstash，logstash存到elasticsearch，最后再通过kibana进行展示检索。

部署kafka

部署kafka我们通过helm直接部署到k8s集群中，如果是使用的tke集群，直接将应用部署到tke集群中即可。

helm repo add bitnami https://charts.bitnami.com/bitnami
helm install my-release bitnami/kafka

创建kafka主题

因为kafka是通过pod启动的，如果没有kafka客户端工具，可以直接登录pod创建主题。

sh kafka-topics.sh --create --zookeeper 10.0.0.187:2181 --replication-factor 1 --partitions 3 --topic log-nginx
sh kafka-topics.sh --create --zookeeper 10.0.0.187:2181 --replication-factor 1 --partitions 3 --topic log-k8s
sh kafka-topics.sh --delete --zookeeper 10.0.0.187:2181 --topic log
sh kafka-topics.sh --zookeeper 10.0.0.187:2181 --list
sh kafka-topics.sh --zookeeper 10.0.0.187:2181 --describe --topic log
sh kafka-console-consumer.sh --bootstrap-server 10.0.0.187:9092 --topic log --from-beginning

这里可以参考上面命令创建主题，还有一些其他常用的命令。

部署filebeat

这里不是filebeat的方式有2种，一种是通过sidecar的方式采集单个业务的日志，还有一种是通过DaemonSet的方式采集所有的容器日志。

sidecar部署filebeat

这里我们通过sidecar的方式部署，采集下nginx日志，具体部署可以参考文档https://www.niewx.cn/mybook/k8s/userd-filebeat-as-sidecar-collect-log.html

这里我们需要改动下filebeat的配置，文档中是投递到es，现在我们要投递到kafka。

apiVersion: v1
data:
  filebeat.yml: |-
    filebeat.inputs:
      - type: log
        paths:
          - /var/log/nginx/access.log
        # tags: ["access"]
        fields:
          app: www
          type: nginx-access
        fields_under_root: true

    setup.ilm.enabled: false
    setup.template.name: "nginx-access"
    setup.template.pattern: "nginx-access-*"

    output:
      kafka:
        enabled: true
        hosts: ["10.0.0.187:9092"]
        topic: log-nginx
        max_message_bytes: 5242880
        partition.round_robin:
          reachable_only: true
        keep-alive: 120
        required_acks: 1

    #  output.elasticsearch:
    #  hosts: ['elasticsearch-master.log:9200']
    #  index: "nginx-access-%{+yyyy.MM.dd}"
kind: ConfigMap
metadata:
  name: filebeat-nginx-config
  namespace: log

DaemonSet部署filebeat

通过DaemonSet的方式部署，采集的是节点容器日志目录，具体的yaml配置如下。

configmap的配置如下，filebeat.autodiscover是filebeat的自动发现功能，对于满足条件的，进行特殊的配置处理，具体的配置方式可以参考官网文档https://www.elastic.co/guide/en/beats/filebeat/current/configuration-autodiscover.html

apiVersion: v1
data:
  filebeat.yml: |-
    filebeat.autodiscover:
      providers:
        - type: kubernetes
          host: ${NODE_NAME}
          hints.enabled: true
          templates:
            - condition:
                equals:
                  kubernetes.namespace: tke-test
            - condition:
                equals:
                  kubernetes.container.name: nginx
              config:
                - type: docker
                  paths:
                    - /var/log/containers/*-${data.kubernetes.container.id}.log
    processors:
      - add_cloud_metadata:
      - add_host_metadata:
    cloud.id: ${ELASTIC_CLOUD_ID}
    cloud.auth: ${ELASTIC_CLOUD_AUTH}
    output:
      kafka:
        enabled: true
        hosts: ["10.0.0.187:9092"]
        topic: log-k8s
        max_message_bytes: 5242880
        partition.round_robin:
          reachable_only: true
        keep-alive: 120
        required_acks: 1
kind: ConfigMap
metadata:
  labels:
    k8s-app: filebeat
  name: filebeat-config
  namespace: log

DaemonSet的yaml参考下面

apiVersion: apps/v1
kind: DaemonSet
metadata:
  labels:
    k8s-app: filebeat
  name: filebeat
  namespace: log
spec:
  selector:
    matchLabels:
      k8s-app: filebeat
  template:
    metadata:
      labels:
        k8s-app: filebeat
    spec:
      containers:
      - args:
        - -c
        - /etc/filebeat.yml
        - -e
        env:
        - name: NODE_NAME
          valueFrom:
            fieldRef:
              apiVersion: v1
              fieldPath: spec.nodeName
        image: elastic/filebeat:7.4.2
        imagePullPolicy: IfNotPresent
        name: filebeat
        resources: {}
        securityContext:
          runAsUser: 0
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /etc/filebeat.yml
          name: config
          readOnly: true
          subPath: filebeat.yml
        - mountPath: /usr/share/filebeat/data
          name: data
        - mountPath: /var/lib/docker/containers
          name: varlibdockercontainers
          readOnly: true
        - mountPath: /var/log
          name: varlog
          readOnly: true
      dnsPolicy: ClusterFirstWithHostNet
      hostNetwork: true
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      serviceAccount: filebeat
      serviceAccountName: filebeat
      terminationGracePeriodSeconds: 30
      volumes:
      - configMap:
          defaultMode: 384
          name: filebeat-config
        name: config
      - hostPath:
          path: /var/lib/docker/containers
          type: ""
        name: varlibdockercontainers
      - hostPath:
          path: /var/log
          type: ""
        name: varlog
      - hostPath:
          path: /var/lib/filebeat-data
          type: DirectoryOrCreate
        name: data

部署elasticsearch

部署elasticsearch采用helm的方式部署

helm repo add elastic https://helm.elastic.co
helm install --name elasticsearch elastic/elasticsearch

部署logstash

logstash的作用主要是将kafka的日志存到elasticsearch里面。

logstash的启动配置如下，这里是多个kafka主题投递到elasticsearch中，input配置topics_pattern，elasticsearch的索引生成加上kafka的主题名称。

apiVersion: v1
data:
  logstash.conf: |-
    input {
      kafka {
         bootstrap_servers => "10.0.0.187:9092"
         codec => json { charset => "UTF-8" }
         consumer_threads => 1
         topics_pattern => ["log-.*"]
       }
     }

    output{
      elasticsearch {
        hosts => ["http://elasticsearch-master:9200"]
        codec => json
        index => "%{[@metadata][topic]}-%{+YYYY.MM.dd}"
        }
      }
kind: ConfigMap
metadata:
  labels:
    type: logstash
  name: logstash-conf
  namespace: log

deployment的yaml文件参考如下

apiVersion: apps/v1
kind: Deployment
metadata:
  name: logstash
  namespace: log
spec:
  replicas: 1
  selector:
    matchLabels:
      type: logstash
  strategy:
    rollingUpdate:
      maxSurge: 25%
      maxUnavailable: 25%
    type: RollingUpdate
  template:
    metadata:
      labels:
        srv: srv-logstash
        type: logstash
    spec:
      containers:
      - command:
        - logstash
        - -f
        - /etc/logstash_c/logstash.conf
        env:
        - name: XPACK_MONITORING_ELASTICSEARCH_HOSTS
          value: http://elasticsearch-master:9200
        image: docker.io/kubeimages/logstash:7.9.3
        imagePullPolicy: IfNotPresent
        name: logstash
        ports:
        - containerPort: 5044
          name: beats
          protocol: TCP
        resources: {}
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /etc/logstash_c/
          name: config-volume
        - mountPath: /usr/share/logstash/config/
          name: config-yml-volume
        - mountPath: /etc/localtime
          name: timezone
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      terminationGracePeriodSeconds: 30
      volumes:
      - configMap:
          defaultMode: 420
          items:
          - key: logstash.conf
            path: logstash.conf
          name: logstash-conf
        name: config-volume
      - hostPath:
          path: /etc/localtime
          type: ""
        name: timezone
      - configMap:
          defaultMode: 420
          items:
          - key: logstash.yml
            path: logstash.yml
          name: logstash-yml
        name: config-yml-volume

部署kibana

部署kibana采用下面yaml部署

configmap配置如下

apiVersion: v1
data:
  kibana.yml: |
    elasticsearch.hosts: http://elasticsearch-master:9200
    server.host: "0"
    server.name: kibana
kind: ConfigMap
metadata:
  labels:
    app: kibana
  name: nwx-kibana
  namespace: log

Deployment的yaml如下

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: kibana
  name: nwx-kibana
  namespace: log
spec:
  replicas: 1
  selector:
    matchLabels:
      app: kibana
  strategy:
    rollingUpdate:
      maxSurge: 25%
      maxUnavailable: 25%
    type: RollingUpdate
  template:
    metadata:
      labels:
        app: kibana
    spec:
      containers:
      - image: kibana:7.6.2
        imagePullPolicy: IfNotPresent
        name: kibana
        ports:
        - containerPort: 5601
          name: kibana
          protocol: TCP
        resources:
          limits:
            cpu: "1"
            memory: 2Gi
          requests:
            cpu: 100m
            memory: 128Mi
        securityContext:
          privileged: false
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
        volumeMounts:
        - mountPath: /usr/share/kibana/config/kibana.yml
          name: kibana
          subPath: kibana.yml
      dnsPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      serviceAccount: default
      serviceAccountName: default
      terminationGracePeriodSeconds: 30
      volumes:
      - configMap:
          defaultMode: 420
          name: nwx-kibana
        name: kibana
